链条可分为：
1，传动链：（A型和B型）传动用短节距精密套筒链、传动用双节距精密滚子链、传动用齿链。其中A型比较常用。
2，输送链：短节距精密滚子输送链、双节距滚子输送链 、长节距输送链、输送用平顶链、输送用短节距精密套筒链、轻型双铰接悬挂输送链。
3，板式链：多为起重链。
4，异型链及各种附件。
双节距链条型号表：
|
链号 |
链号 |
节距 |
滚子直径 |
内节内宽 |
销轴直径 |
销轴长度 |
内链板高度 |
链板厚度 |
极限拉伸载荷 |
平均拉伸载荷 |
每米长重 |
|
|
P |
d1 max |
b1 min |
d2 max |
L max |
Lc max |
h2 max |
T max |
Q min |
Qo |
q |
||
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
kN |
kN |
kg/m |
||
|
C208ASS C208ALSS |
C2040SS C2042SS |
25.40 |
7.95 15.88 |
7.85 |
3.96 |
16.6 |
17.8 |
12.0 |
1.50 |
8.46 |
10.02 |
0.50 0.84 |
|
C208AHSS |
C2040HSS |
25.40 |
7.95 |
7.85 |
3.96 |
18.8 |
19.9 |
12.0 |
2.03 |
8.46 |
10.32 |
0.65 |
|
C208BSS C208BLSS |
|
25.40 |
8.51 |
7.75 |
4.45 |
16.7 |
18.2 |
11.8 |
1.60 |
10.80 |
11.64 |
0.55 0.89 |
|
C210ASS C210ALSS |
C2050SS C2052SS |
31.75 |
10.16 19.05 |
9.40 |
5.08 |
20.7 |
22.2 |
15.0 |
2.03 |
13.32 |
16.86 |
0.78 1.27 |
|
C212ASS C212ALSS |
C2060SS C2062SS |
38.10 |
11.91 22.23 |
12.57 |
5.94 |
25.9 |
27.7 |
18.0 |
2.42 |
19.08 |
22.08 |
1.12 1.61 |
|
C212AHSS C212AHLSS |
C2060HSS C2062HSS |
38.10 |
11.91 22.23 |
12.57 |
5.94 |
29.2 |
31.6 |
18.0 |
3.25 |
19.08 |
24.96 |
1.44 2.07 |
|
C216ASS C216ALSS |
C2080SS C2082SS |
50.80 |
15.88 28.58 |
15.75 |
7.92 |
32.7 |
36.5 |
24.0 |
3.25 |
34.02 |
39.42 |
2.08 3.12 |
|
C216AHSS C216AHLSS |
C2080HSS C2082HSS |
50.80 |
15.88 28.58 |
15.75 |
7.92 |
36.2 |
39.4 |
24.4 |
4.00 |
34.02 |
42.00 |
2.54 3.58 |
|
C220ASS C220ALSS |
C2100SS C2102SS |
63.50 |
19.05 39.67 |
18.90 |
9.53 |
40.4 |
44.7 |
30.0 |
4.00 |
53.10 |
61.56 |
3.01 4.83 |
|
C220AHSS C220AHLSS |
C2100HSS C2102HSS |
63.50 |
19.05 39.67 |
18.90 |
9.53 |
43.6 |
46.9 |
30.0 |
4.80 |
53.10 |
67.44 |
3.56 5.38 |
|
C224ASS C224ALSS |
C2120SS C2122SS |
76.20 |
22.23 44.45 |
25.22 |
11.10 |
50.3 |
54.3 |
35.7 |
4.80 |
76.20 |
88.38 |
4.66 7.66 |
|
C224AHSS C224AHLSS |
C2120HSS C2122HSS |
76.20 |
22.23 44.45 |
25.22 |
11.10 |
53.5 |
57.5 |
35.7 |
5.60 |
76.20 |
96.54 |
5.26 8.26 |
|
C232ASS C232ALSS |
C2160SS C2162SS |
101.60 |
28.58 57.15 |
31.75 |
14.27 |
64.8 |
69.6 |
47.8 |
6.40 |
136.08 |
167.34 |
8.23 11.95 |
|
C232AHSS C232AHLSS |
C2160HSS C2162HSS |
101.60 |
28.58 57.15 |
31.75 |
14.27 |
68.2 |
73.0 |
47.8 |
7.20 |
136.08 |
171.48 |
9.06 12.77 |
